Solution to Shadow Problem

Moore's article technique for eliminating shadows&

Four directional projection light system (Zenith Alpha HS&Zenith Alpha UHS)/

Five directional projection light system (Zenith Alpha HS+)

Solution to Mirror Problems

Small component detection (0402mm)

Multi frequency Moire technology

Large measurement range+accuracy (measurement range issue)

Real time PCB deviation compensation

Bending compensation

(Pad Referencing+Multi Frequency Moire Technology)

Dark component and white component position component body

Full 3D measurement

Solder micro warping detection

Solder connection surface inspection

3D polarity detection

Component crack detection

model

Camera resolution

FOVsize(MM)

Detection**    speed

maximum

Height

measurement

Height precision

(Correction module)

Illumination

ALPHA HS

6.5M 20μm

8M 10μm

8M 15μm

51 x 51 mm

28 x 28 mm

42 x 43 mm

55.3 cm2/sec (0.47 sec/FOV)

17.8 cm2/sec (0.44 sec/FOV)

36.9 cm2/sec (0.49 sec/FOV)

3 mm

4 mm

4 mm

±3%

IR-RGB

LED

(Dome

Styled

Illumination)

ALPHA HS+

6.5M 20μm

8M 15μm

51 x 51 mm

42 x 43 mm

49.1 cm2/sec (0.53 sec/FOV)

32.1 cm2/sec (0.55 sec/FOV)

20 mm

25 mm

ALPHA UHS

12M 10μm

12M 15μm

12M 10μm

61 x 46 mm

28.2 cm2/sec (0.45 sec/FOV)

57.3 cm2/sec (0.49 sec/FOV)

4 mm

correspondence

Conveyor width adjustment

Automatic

Correspondable input format

Front / Rear Fixed (factory setting)

Software

Correspondable input format

GERBER Data (274X, 274D), ODB++, Placement File, Mounter JOB file, Allegro,

Zuken, Mentor (Option)

Programming Software

ePM-AOI, AOI GUI

Statistical management tools

SPC Plus, Review Station

Convenience of interface operation

Library, KYCAL (Automatic camera/Illumination/height)

Operation System

WINDOWS 10 IOT ENTERPRISE LTSC 2019

Add-on

Solutions

- 1D & 2D Handy Barcode Reader

- Offline SPC Pro Station

- KSMART Solutions

- 1D & 2D Inline Barcode Reader

- Review Station

(Monitoring & Analysis, Remote Access,

- Standard Calibration Target

- Whole Board Foreign Material (WFMI)

Offline Programming Optimizer, Link Data Analysis,

Model

L

XL

Single Lane

Dual Lane

Single Lane

Dual Lane

Max PCB

490 x 510 mm

(19.29 x 20.01 in)

Single Model

490 x 580 mm

(19.29 x 22.83 in)

690 x 690 mm

(27.17 x 27.17 in)

Single model

690 x 580 mm

(27.17 x 22.82 in)

Dual Model

490 x 320 mm

(19.29 x 12.60 in)

Dual Model

690 x 320 mm

(27.17 x 12.60 in)

Min PCB

50 x 50 mm (1.97 x 1.97 in)

PCB thickness

0.4 ~ 5 mm (0.02~0.2 in)

0.4 ~ 8 mm (0.02 ~ 0.31 in)

Max PCB weight

4kg (8.82 lbs)

10kg (22.05 lbs)

Machine weight

600kg (1322.77 lbs)

700kg (1543.24 lbs)

750kg (1653.47 lbs)

Bottom clearance

50mm(1.97 in)

consumption

220 VAC ± 10%, 1 Phase, 50/60Hz, 5Kfg/cm2 (0.45MPa)

W

1000 mm (39.37 in)

1200 mm (47.25 in)

D

1295mm(50.98 in)

1475mm (58.07 in)

1475 mm(58.07 in)

H

1627 mm (64.06 in)
