JUKI RX-7R Hard Disk Assy 40152327

Specifications:

JUKI RX-7R Spare part List:

X frame assy - Left
Ref.No. Part Number Description Q'ty
1 EZX-258-658-62 HEATSINK ASSY
2 EZ1-492-149-11 DRIVER, PULSE MOTOR
3 EZ1-492-200-21 FAN ASSY (Y) FAN
4 EZ1-492-231-23 MOTOR ASSY (Y)
5 EZ1-492-235-25 MOTOR ASSY (Z)
6 EZ1-492-237-23 SCALE ASSY (X)
7 EZ1-492-245-11 UNIT,CAMERA PC BOARD(TS-479-*)
8 EZ1-855-265-11 MOTOR, SERVO (HG-KR23)
9 EZ2-580-592-01 SCREW, +PSW M3X8
10 EZ4-454-731-01 LINEAR ROLLERWAY (MXSG15C1R440)
11 EZ4-454-733-01 BEARING (7000), ANGULAR
12 EZ4-454-734-01 BELT (275-EV5GT-12), TIMING
13 EZ4-454-735-01 LOCK (MC-8-19), MECHANICAL
14 EZ4-454-736-01 LOCK (MC-14-26), MECHANICAL
15 EZ4-454-738-01 BEARING (MTA06-15), ANGULAR
16 EZ4-454-739-02 LINEAR WAY (MLC9C2R180)
17 EZ4-454-740-01 SCREW (BLK0606S-3G1), BALL
18 EZ4-454-741-01 COUPLING (SFC-010SA2-5B-5B)
19 EZ4-454-946-01 X PULLEY
20 EZ4-454-947-01 PULLEY, X DRIVING
21 EZ4-455-207-02 GREASE COVER (X, A)
22 EZ4-455-208-02 GREASE COVER (X, B)
23 EZ4-455-209-02 STOPPER (X, S)
24 EZ4-455-210-01 COLLAR, HEAT INSULATING
25 EZ4-455-211-01 WASHER, HEAT INSULATING
26 EZ4-455-238-12 BEARING HOLDER (X, F)
27 EZ4-455-239-01 MOTOR BRACKET (X)
28 EZ4-455-241-01 BEARING RETAINER (X)
29 EZ4-455-242-02 TENSION PLATE (X)
30 EZ4-455-248-04 X FRAME (L) X
31 EZ4-455-277-02 HOLDER (Z), BEARING
32 EZ4-455-279-02 BRACKET, MOTOR
33 EZ4-455-283-02 RETAINER, BEARING
34 EZ4-455-284-01 HOLDER, NUT (Z)
35 EZ4-455-285-03 Z FRAME (L) Z
36 EZ4-455-293-01 URETHANE STOPPER, Z
37 EZ4-455-294-01 COLLAR, Z STOPPER Z
38 EZ4-455-668-01 FAN, BRACKET FAN
